The drawing and table below summarize standard geometric and optical quality specifications for our material and laser rods

The table shows selected lengths and diamters only. Any size rod up to 15mm diameter and 250mm in length can readily be made. Different geometries (such as slabs) are also available

For more sizes and end finish options, download our Nd:YAG Product Brochure

 Rod Size

 Standard Grade

 Premium Grade

 Standard [Nd]: 1.1 Atom%

 Low [Nd]: 0.8 Atom%

Tolerance of [Nd] Over Rod Length

delta [Nd]

50

3

>25

<0.19

>30

<0.13

±.08

0.06

±.07

0.05

50

4

<0.21

<0.15

50

5

<0.24

<0.16

100

4

>22

<0.28

>27

<0.18

±.08

0.13

±.06

0.09

100

5

<0.32

<0.21

100

6

<0.36

<0.23

100

6.35

<0.37

<0.24

150

6.35

>20

<0.48

>25

<0.30

±.05

0.18

±.04

0.13

150

8

<0.58

<0.35

150

9.52

<0.67

<0.40

200

8

>19

<0.71

>24

<0.42

±.02

0.23

±.02

0.17

200

9.53

<0.82

<0.49

200

10

<0.86

<0.51

 Type

Reflectivity

Damage Threshold

Damage Threshold

(%R per Surface)

(<20nS Pulse, GW/cm^2)

(CW, kW/cm^2)

 AR @1064nm

 <0.15

  >1.4

>25

 HR @1064nm

 >99.9

  >1.0

>25
